VisualARQ Styles Library

VisualARQ styles are stored in .val files (“VisualARQ library” files). Import them into your document with the vaStylesImport command.

Default libraries in VisualARQ templates

VisualARQ (evaluation and commercial versions) come with a default library of object styles. They are available in VisualARQ templates, but you can get the .val files to import these styles in documents started from Rhino templates from these directories:

• Rhino 7: C:\Program Files\AsuniCAD\VisualARQ 3\RHINO7\en-US\Libraries
• Rhino 8: C:\Program Files\AsuniCAD\VisualARQ 3\RHINO8\en-US\Libraries

Users custom objects

• New VisualARQ object styles shared by users on food4Rhino

Structural profiles libraries:

• Australian structural profiles library
• Chinese structural profiles library
• DIN structural profiles library
• Indian structural profiles library
• Japanese Industrial Standards (JIS)
• Korean structural profiles library
• UK standard profiles
• Wood structural profiles library

Structural profiles included in VisualARQ templates:

• European standard profiles library (metric)
• American standard profiles library (AISC) (imperial)
